PHE 90
|
CLEANING AND CARE
Wipe off powder coated surfaces with soft, moist rag. Do not clean heater with cleaners that are
combustible or corrosive.
Remove debris from the burner to keep it clean and safe for use.
Cover the burner unit with the optional protective cover when the heater is not in use.
1. Reflector
2. Upper protective grille
3. Protective grille
4. Control knob
5. Cylinder housing
6. Base
PARTS AND SPECIFICATIONS
Specifications
Use propane or butane.
Max. wattage: 11000 watts
Min. wattage: 5000 watts
Consumption: 800gr/h
Using the proper regulator according to outlet pressure of regulator as showed in the table above.
