- 8 -
CHRONOS Programmable Thermostat User Manual
INSTALLATION
t The programmable thermostats of Chronos series are designed for wall-mountig .
Alternatively they can be installed to cover three-module in built box.
t 5IFQSPHSBNNBCMFUIFSNPTUBUNVTUCFJOTUBMMFEBUBIFJHIUBUBCPVUNBCPWF
the floor, away from direct sunlight, away from doors, windows, heat sources,
locations with excess or total lack of ventilation.
 Connect the wires to the terminal
blocks of the base, as shown in the
iXJSJOHEJBHSBNTw.
 Fix the base on the wall using the
screws supplied.
 Insert the batteries into the battery
compartment on the back of the
programmable thermostat, respecting
the polarity
 Attach the programmable thermostat
to the base, at first mating teeth on
the higher side.
1
1
2
Attention: it’s not possible to make no programming or modification of the set
parameters until the instrument is not correctly installed on wall-mounted base
