Field
(22)
will display the writing
“ESt=”
and on field
(16)
the
selected option will flash. Choose
“yES”
or
“nO”
to enable or disable
the display of the temperature
measured by the external probe.
If you choose
“yES”
when you exit
the menu, field
(15)
will display the
writing
“EXT”
followed by the value
of the temperature measured by the
probe.
The characteristics of the probe are the following:
• Degree of protection: IP66
• Cable length: 2 meters (extensible up to 40 meters with a bipolar cable
min section 1 mm
2
)
• Operating temperature: -40 °C ÷ +60 °C
Code Model Capacity
329907 X.Temp 100K -40 °C ÷ +60 °C
Choosing the regulation probe
In case an external probe is present, it is possible to choose whether to use
the internal probe or the external one as a regulation sensor.
Field
(22)
will display the writing
“SnS=”
and on field
(16)
the value
currently set will flash.
Using the
“ ”
and
“ ”
keys,
choose
“Int”
if you want to use the
internal probe or
“Est”
if you want
to use the external probe and press
“ ”
to confirm the choice.
