Orbit OBRPR5 - Page 6

Step 7
1. Connect the console wire (B-2) insert the back side of computer.
2. Connect the delivered of hand pulse wire (B-3) with the outlet from back side of computer.
3. Place the console (A-1) to the bracket of front post, fix tight with the enclosed screws (A-2).
4. Plug in the power adaptor (R-4) to the equipment.
