Orbit X304 - Assembly Step 10: Assembly Instructions

26
Assembly step（10）drawing
Assembly step（10）assembly instrucon
1
Fix shield-74 fastening on main frame using M8x20 hexagon bolt-76, Φ8 washer-77 and M8
lock nut-78
2
Fix barbell plate holder-75 on main frame using M8x20 hexagon bolt-76, Φ8 washer-77
