A . FRONT DISPLAY
A four line easy-to-read LCD each with specific purposes that
relate to weather forecasting, temperature, or clock / calendar
/ alarm functions.
A1 . WEATHER FORECAST WINDOW
- Graphically illustrates a weather forecast
A2. REMOTE TEMPERATURE WINDOW
- Displays current temperature, remote sensor unit
- Indicates the minimum / maximum remote temperature
- Displays remote temperature as Fahrenheit (°F) or Celsius (°C)
- Indicates when the remote sensor battery is low
- Indicates the remote sensor channel
A3. INDOOR TEMPERATURE WINDOW
- Displays current indoor temperature
- Indicates minimum / maximum indoor temperature
- Displays indoor temperatures as Fahrenheit (°F)/ Celsius (°C)
- Indicates when main unit battery is low
A4. TIME / DATE / ALARM WINDOW
- Displays the current time, date (day, month, and day-of-the-
week), or alarm times
- Current time and date in another time Zone
- Radio Frequency (RF) status indicator [
]
- “ALARM ON” icon indicates when the alarm is active [
]
- Alarm indicator [ ]
B. CONTROL BUTTONS
B1. CHANNEL BUTTON
Sets the remote sensor channel.
B2. [MEM] BUTTON
Displays minimum and maximum temperature readings, and
erases memory data
B3. ALARM [
] BUTTON
Displays the alarm time, or changes the alarm set time
B4. MODE/SET BUTTON
Changes the display mode of the clock, and alters time/date
setting
B5. UP [
] DOWN [ ] BUTTONS
Sets the increase or decrease in the value of a setting.
B6. [AL ON/OFF] BUTTON
Activates and deactivates the alarm
B7. °C/°F SLIDE SWITCH
Selects between Centigrade (°C) or Fahrenheit (°F) display
C. OTHER FEATURES
C1. BATTERY COMPARTMENT
Accommodates four UM-3 or “AA” size alkaline batteries
C2. RESET SLOT
Resets the unit by returning all setting to their default values
C3. REMOVABLE TABLE STAND
For mounting the remote sensor on a flat horizontal surface.
C4. RECESSED WALL-MOUNT HOLE
For mounting to a wall or vertical surface
