2
GB
A Two-line LCD
Displays the time, date, alarm status and temperature
B [ ] Battery-Low icon
Icon is displayed when the battery power is low
C[
] Radio-Reception Signal
Indicates the strength of Clock signal reception
D[
] Alarm-on icon
Icon is displayed when the alarm is activated
E[
] Alarm icon
Indicates that the alarm set time is displayed on the LCD
F CLOCK button
Alternates between the calendar clock display modes and
activation of the calendar clock setting mode
G UP [
] and DOWN [ ] buttons
Increases or decreases the value of a setting
H ALARM button
Displays the alarm time or sets the alarm status
I[
] button
Turns on the backlight and projector for 5 seconds and
activates the snooze function when daily alarm sounds
J Projection Lens
Lens from which time is projected
K Adjustable Projector
180° Tilt - swivel projection housing
L[ ] IMAGE ROTATION knob
90° (left or right) image rotation
M FOCUS Knob
Adjusts the focus of the projection
N 180° ROTATION button
Horizontal flip rotation of image
O PROJECTION LIGHT ON - switch
Enables the projection feature to be on continuously
P Battery compartment
Accommodates two UM-3 or “AA” size batteries
Q RESET button
Returns all user-programmed settings to the factory default
setting
BATTERY INSTALLATION
The unit uses two (2) UM-3 or “AA” size 1.5V batteries.
To insert batteries:
1. Gently pull battery compartment door forward to access the
battery compartment.
2. Insert the batteries strictly according to the polarities shown
therein.
3. Replace the battery compartment door.
When the low battery indicator icon [ ] is displayed, replace
batteries with fresh batteries.
