SPECIFICATIONS
Specifications
Model No. OR25TBS-2 OR25TKO-2 OR30TBS-2 OR30TKO-2 OR35TBS-2 OR35TKO-2
Engine Briggs & Stratton
CR950
208cc
Kohler
SH265
196cc
Briggs Stratton
XR1150
250cc
Kohler
SH265
196cc
Briggs & Stratton
XR1450
306cc
Kohler
CH395
277cc
Maximum
Splitting Force*
25 Tons 25 Tons 30 Tons 30 Tons 35 Tons 35 Tons
Cycle Time* 11.2-seconds 11.2-seconds 12.9-seconds 12.9-seconds 12.7-seconds 12.7-seconds
Pump 2-stage,
14 GPM
2-stage,
14 GPM
2-stage,
14 GPM
2-stage,
14 GPM
2-stage,
17 GPM
2-stage,
17 GPM
Cylinder 4" x 24" with 1.75"
inner rod diameter
4" x 24" with 1.75"
inner rod diameter
4.5" x 24" with 1.75"
inner rod diameter
4.5" x 24" with 1.75"
inner rod diameter
5" x 24" with 2"
inner rod diameter
5" x 24" with 2"
inner rod diameter
Valve 3915 PSI 3915 PSI 3625 PSI 3625 PSI 3625 PSI 3625 PSI
Maximum
Log Length
25.5" 25.5" 25.5" 25.5" 25.5" 25.5"
Wheels 4.5" x 16" diameter 4.5" x 16" diameter 4.5" x 16" diameter 4.5" x 16" diameter 4.5" x 16" diameter 4.5" x 16" diameter
Wedge Height 8" tall wedge 8" tall wedge 8" tall wedge 8" tall wedge 8" tall wedge 8" tall wedge
Hydraulic Capacity 4.5 gallons 4.5 gallons 6 gallons 6 gallons 6.6 gallons 6.6 gallons
Filter In-tank filter In-tank filter In-tank filter In-tank filter In-tank filter In-tank filter
Height -- Vertical 71" 71" 71" 71" 71" 71"
-- Horizontal 40" 40" 40" 40" 40" 40"
Width 48" 48" 48" 48" 48" 48"
Shipping Weight 578 lbs. 578 lbs. 644 lbs. 644 lbs. 699 lbs. 710 lbs.
* Tonnage and cycle times vary dependent upon mechanical and environmental conditions.
General Information
WARNING
Some illustrations in this manual show the equipment with safety shields removed to provide a better view.
This equipment should never be operated with any necessary safety shielding removed.
The purpose of this manual is to assist you in operating and maintaining your 3-point equipment. Read it carefully. It furnishes
information and instructions that will help you achieve years of dependable performance. These instructions have been
compiled from extensive field experience and engineering data. Some information may be general in nature due to unknown
and varying operating conditions. However, through experience and these instructions, you should be able to develop
procedures suitable to your particular situation.
The illustrations and data used in this manual were current at the time of printing but, due to possible inline production
changes, your machine may vary slightly in detail. We reserve the right to redesign and change the machines as may be
necessary without notification.
Throughout this manual, references are made to right and left directions. These are determined by standing behind the
equipment, facing the direction of the forward travel. Blade rotation is counterclockwise as viewed from the top of the cutter.
