4
parameters return to the ir initial stat us . Once reset, the Splicer
is capable of splicing again.
2.
2.
2.
2. 9
9
9
9 Alig
Alig
Alig
Alig n
n
n
n ment
ment
ment
ment
The operation is to adjust the two fibers, so that they are in the
same direction. If the y are not properly aligned, there will be
deviations in the horizontal (x-axis) and vertical (y-axis)
directions, which are called radial offset. The align ment
operation controls the radial offset within the allowable range.
2.
2.
2.
2. 10
10
10
10 Estimated
Estimated
Estimated
Estimated Splice
Splice
Splice
Splice Loss
Loss
Loss
Loss
The splicer calculates the loss at the splicing point according to
the fiber images. The results are reliable when the splic ing is
done correctly.
2.11
2.11
2.11
2.11 Fiber
Fiber
Fiber
Fiber Protection
Protection
Protection
Protection Sleeve
Sleeve
Sleeve
Sleeve
Used to protect the splicing point, as shown in the following
figure.
Figure 2-3
Heat shrink tube
Glass ceramics
Tube of hot melt
60mm
