19
to enter menu of a djustment of splice p arameters .
Specification
Specification
Specification
Specification of
of
of
of Splice
Splice
Splice
Splice Parameters
Parameters
Parameters
Parameters
All items in the parameters group as table 7-1.
Parameter Modification ：
a) Use the or key to move the cursor to the item
that needs to be adjusted , and then it means this parameter
could be modified.
b) Then adjust the parameter to the ideal value with
ARC
/+
or
X - Y / -
key.
c) The other parameters can be modified in the same way.
Table 7-1
Item Range Unit Default Value
P refuse Time
00 ～ 99
10ms 05
Fuse Time
00 ～ 99
100ms 14
Prefuse Power
00 ～ 99
0.1mA 30
Fuse Power
00 ～ 99
0.1mA 30
Overlap
00 ～ 40
2 µ m 07
End Angle
0.5 ～ 2 .0 1.0 °
2.0
GAP
00 ～ 09
2 µ m 04
