Origin SINGLE BEDFRAME - Final Frame Assembly

To Next Page

To Previous Page

INSTALLATION

Mattress

Platform (M)

STEP8：

Place the

Cross Bars (K) to Cross Bars Holders (L) in correct position and

place the Mattress Platform (M) on the Cross Bars (K) as feature - 8.

Feature - 8

STEP7：

Install the

Head board Assembly & Foot board Assembly to Side board - LH

(A) & Side board - RH (B) and place the Crescent Shape Plastic Pads (S)

and use 14mm Spanner (T) to lock and tighten the M8 Nuts (Q) as feature -

Feature - 7

Cross Bars

(K)

Side board

- LH(A)

Cross Bars

Holders (L)

Side board -

RH (B)

Head board

Assembly

Foot board

Assembly
