INSTALLATION

Crescent

Shape

Plastic

Pads (S)

Head board Assembly ( Rear)

Feature - 6

Head board

- Lower(F)

STEP6：

Install the

Head End Legs - LH (I) & Head End Legs - RH (J) to Head board

Upper (D),Head board - Middle (E) & Head board - Lower (F) and place the

Crescent Shape Plastic Pads (S) and use 14mm Spanner (T) to lock and

tighten the M8 Nuts (Q) as feature - 5 & 6

Head board Assembly ( Front)

Feature - 5

Head board -

Middle (E)

Head End

Legs - RH (J)

M8 Nuts (Q)

Head board -

Upper (D)

Head End

Legs - LH (I)

Cross Bars

Holders (L)
