Origin SINGLE BEDFRAME User Manual

8
INSTALLATION
STEP5：
Install the Foot board (C) to Foot End Legs - LH (G) & Foot End Legs - RH
(H) and place the Crescent Shape Plastic Pads (S) and use 14mm Spanner
(T) to lock and tighten the M8 Nuts (Q) as feature - 4 .
Foot board Assembly
Feature - 4
STEP4：
Install the Wood Locating Pins - Small (O) to Cross Bars Holders (L) and
place Cross Bars Holders (L) to the Head board - Lower (F) & Foot board (C)
in correct position and then use phillips screwdriver to lock and tighten the
Cross CSK Tapping Screws (R) lock and tighten as feature - 3 .
Head board - Lower(F)
Foot board(C)
Feature - 3
Foot End Legs
- LH (G)
Cross CSK Tapping
Screws (R)
Foot
board (C)
M8 Nuts (Q)
Wood Locating Pins
- Small (O)
Crescent Shape
Plastic Pads (S)
Foot End Legs
- RH (H)
Cross Bars
Holders (L)
Cross Bars
Holders (L)
