* ALL SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE.

ENCLOSURE RECOMMENDATIONS

C10D2 C10D4 C12D2 C12D4 C15D2 C15D4

Nominal Impedance 4 ohm 2 or 8 ohm 4 ohm 2 or 8 ohm 4 ohm 2 or 8 ohm

RE (DC resistance) 3.72 7.15 3.6 6.8 3.75 7.15

Levc (coil inductace) 1.97 mH 2.06 mH 1.28 mH 2.15 mH 1.2 mH 1.95 mH

Sensitivity @ 2.84V/1m 84.38 dB 85.72 dB 89.86 dB 86.98 dB 90.28 dB 89.04 dB

Fs (free air resonance) 44.15 Hz 41.47 Hz 37.71 Hz 39.59 Hz 40.27 Hz 39.48 Hz

Qms (mechanical Q) 6.16 6.79 6.49 6.13 6.86 6.86

Qes (electrical Q) 0.67 0.69 0.74 0.8 0.96 1.04

Qts (totalQ) 0.6 0.63 0.67 0.71 0.84 0.9

BL (force factor) 14.57 TM 17.22 TM 12.98 TM 17.12 TM 13.86 TM 18.11 TM

Sd (piston area) 0.032 sq. m 0.032 sq. m 0.05 sq. m 0.05 sq. m 0.085 sq. m 0.085 sq. m

49.75 sq. in. 49.75 sq. in. 78.43 sq. in. 78.43 sq. in. 132.52 sq. in. 132.52 sq. in.

Vas (volume acoustic suspension) 13.68 liters 19.42 liters 43.63 liters 41.27 liters 81.64 liters 87.09 liters

0.48 cu. ft. 0.68 cu. ft. 1.54 cu. ft. 1.45 cu. ft. 2.88 cu. ft. 3.07 cu. ft.

Xmax (linear excursion) 10 mm 10.3 mm 9.25 mm 10.3 mm 8.25 mm 8.25 mm

0.39 in. 0.4 in. 0.36 in. 0.4 in. 0.32 in. 0.32 in.

Power (continuous thermal power handling) 200 watts 200 watts 200 watts 200 watts 200 watts 200 watts

Power (peak thermal power handling) 400 watts 400 watts 400 watts 400 watts 400 watts 400 watts

Outside Diameter 10.25 in. 10.25 in. 12.25 in. 12.25 in. 15.25 in. 15.25 in

Mounting Diameter 9.25 in. 9.25 in. 11 in. 11 in. 13.75 in. 13.75 in.

Mounting Depth 5 in. 5 in. 5.25 in. 5.25 in. 7 in. 7 in.

Basket Displacement 115 cu. in. 115 cu. in. 209 cu. in. 209 cu. in. 420 cu. in. 420 cu. in.

1.9 liters 1.9 liters 3.4 liters 3.4 liters 6.9 liters 6.9 liters

Voice Coil Diameter 2.0 in. 2.0 in. 2.0 in. 2.0 in. 2.0 in. 2.0 in.

51 mm 51 mm 51 mm 51 mm 51 mm 51 mm

Sealed Enclosure Volume 0.66 cu. ft. 0.50 cu. ft. 1.5 cu. ft. 1.75 cu. ft 2.5 cu. ft. 3.5 cu.ft.

Vented Enclosure Volume 0.85 cu. ft. 0.85 cu. ft . 1.15 cu. ft. 1.15 cu. ft. 2.25 cu. ft 2.25 cu. ft.

Port Diameter (inside diameter) 3 in. 3 in. 4 in. 4 in. 5 in. 5 in.

Port Length 6.7 in. 6.7 in. 11.72 in. 5.15 in. 7.07 in. 7.55 in.

Enclosures include basket and port displacment
