FEATURES
1 Polypropylene dust cap - moisture and UV resistant.
2 Oversized NBR (Nitrile-butadiene Rubber) surround for linear
controlled long excursion.
3 Vented paper cone - moisture and UV resistant.
4 Custom stamped steel frame.
5 Vented Kapton voice coil former (10” & 12" uses 1.5" voice coil
former, 15” use a 2" voice coil former).
6 9mm steel front plate.
7 Large 2 stack ceramic magnets.
8 8mm steel back plate/pole piece T yoke assembly.
9 0.75" vent. Part of the enhanced voice coil cooling system (forced
convection).
10 PVC magnet protector.
11 High temperature Copper 4 ohm voice coil.
12 Venting in voice coil former. Part of the enhanced voice coil cooling
system (forced convection).
13 Interlaced Conex spider with stitched and looped tinsel leads
attached.
14 Push Terminals.
15 Reversible PVC mounting gasket.
13
12
15
14
11
10 9
1 2
3
6
5
7
4
8
