Orion HCCA154 User Manual

SPECIFICATIONS
4
Model Number HCCA102 HCCA104 HCCA122 HCCA124 HCCA152 HCCA154
Size 10” 10” 12” 12” 15” 15”
Fs (free-air resonance, Hz) 42.51 44.3 32.3 33.2 28.13 30.02
Vas (equivalent compliance, cu.
ft.)
0.31029 0.31699 0.89274 0.93157 2.95746 2.82259
Vas (equivalent compliance,
liters)
8.79 8.98 25.29 26.39 83.78 79.96
Qms (Q, mechanical) 7.16 5.99 5.08 4.16 5.17 4.38
Qes (Q, electrical) 0.48 0.52 0.5 0.54 0.55 0.61
Qts (total driver Q) 0.45 0.48 0.45 0.48 0.5 0.54
Re (DC resistance, ohms) 3.9 7.4 4 7.4 4 7.3
Z (nominal impedance, ohms) 2x2 4x2 2x2 4x2 2x2 2x2
Le (inductane, mh) 1.93 2.93 2.61 3.67 2.59 3.68
Efciency (1W @ 1M, db) 86.51 83.66 84.22 83.38 87.2 87.4
Xmas (one way linear excursion,
in.)
1.01948 1.01948 1.18939 1.18939 1.18939 1.18939
Xmas (one way linear excursion,
mm)
25.89 25.89 30.1875 30.18 30.18 30.18
RMS POWER WATTS 2000 2000 2500 2500 2500 2500
NOMINAL POWER WATTS 4000 4000 5000 5000 5000 5000
MAX MUSIC POWER WATTS 8000 8000 10000 10000 10000 10000
Mms (total moving mass, grams) 250 225 425 386 500 460
Cms (mechanical compliance,
m/N)
0.000056 0.000057 0.000057 0.00006 0.00005 0.000061
BI (motor strength, Tesla-M) 23.3 29.86 26.27 33.2 25.34 32.21
Sd (effective radiating area, sq.
cm.)
333.29 333.29 559.9 559.9 962.11 962.11
Sd )effective radiating area, sq.
in.)
51.66 51.66 86.78 86.78 149.13 149.13
Frequency Range (Hz) 32-100 33-100 24-100 25-100 21-100 22-100
Energy Bandwidth Product
(EBP)**
89 85 65 61 51 49
