72
Chamber, front and rollers
4 pcs on each side
Grease nipple No: 23,24,25,26,27,28,29 and 30
Chamber tailgate liing cylinders
2 pcs on each side
Grease nipple No: 31,32,33 and 34
Belt under, rear support
1 pcs on each side.
Grease nipple No: 35 and 36
Belt under, rear support
Chamber front and rollers
Chamber tailgate liing cylinder
