ORTEC GEM30P4 - Streamline GEM Detector Dimensions

GEM Series Coaxial HPGe Detector
Product Configuration Guide
12
Standard or LB XLB
Endcap Model (dia. mm) -70 -76 -83 -95 -108 -70 -76 -83 -95 -108
% Efficiencies available in this
endcap size
0–35 25–45 25–65 60–110 120-150 0–35 25–45 25–65 60–110 120-150
Dim. Unit Tol.
A
mm
(in)
0.3
(0.01)
70
(2.75)
76
(3.0)
83
(3.25)
95
(3.75)
108
(4.25)
70
(2.75)
76
(3.0)
83
(3.25)
95
(3.75)
108
(4.25)
B
mm
(in)
0.3
(0.01)
75
(2.95)
88
(3.45)
88
(3.45)
100
(3.95)
113
(4.45)
75
(2.95)
88
(3.45)
88
(3.45)
100
(3.95)
113
(4.45)
C
mm
(in)
5
(0.2)
134
(5.3)
132
(5.2)
134
(5.3)
160
(6.3)
197
(7.8)
160
(6.3)
157
(6.1)
160
(6.3)
185
(7.3)
197
(7.8)
D
mm
(in)
8
(0.3)
246
(9.7)
259
(10.2)
259
(10.2)
284
(11.2)
322
(12.7)
272
(10.7)
284
(11.2)
284
(11.2)
310
(12.2)
322
(12.7)
E
mm
(in)
18
(0.7)
916
(36.1)
932
(36.7)
932
(36.7)
957
(37.7)
995
(39.2)
941
(37.1)
958
(37.7)
958
(37.7)
983
(38.7)
995
(39.2)
EM
mm
(in)
19
(0.75)
917
(36.1)
933
(36.7)
933
(36.7)
958
(37.7)
996
(39.2)
942
(37.1)
959
(37.8)
959
(37.8)
984
(38.7)
996
(39.2)
F
mm
(in)
10
(0.4)
368
(14.5)
381
(15.0)
381
(15.0)
406
(16.0)
445
(17.5)
394
(15.5)
406
(16.0)
406
(16.0)
432
(17.0)
445
(17.5)
H
mm
(in)
18
(0.7)
351
(13.8)
364
(14.3)
364
(14.3)
390
(15.3)
428
(16.9)
X
X
X
X
X
X
X
X
X
X
HB
mm
(in)
0.3
(0.1)
73
(2.9)
85
(3.4)
85
(3.4)
98
(3.9)
111
(4.4)
X
X
X
X
X
X
X
X
X
X
HC
mm
(in)
5
(0.2)
134
(5.3)
132
(5.2)
135
(5.3)
160
(6.3)
199
(7.8)
X
X
X
X
X
X
X
X
X
X
HD
mm
(in)
10
(0.4)
162
(6.4)
175
(6.9)
175
(6.9)
200
(7.9)
238
(9.4)
X
X
X
X
X
X
X
X
X
X
J
mm
(in)
10
(0.4)
380
(15)
393
(15.5)
393
(15.5)
418
(16.5)
456
(18)
405
(16)
418
(16.5)
418
(16.5)
444
(17.5)
456
(18)
L
mm
(in)
10
(0.4)
338
(13.3)
351
(13.8)
351
(13.8)
376
(14.8)
414
(16.3)
363
(14.3)
376
(14.8)
376
(14.8)
401
(15.8)
414
(16.3)
M
mm
(in)
8
(0.3)
516
(20.3)
X
X
X
X
X
X
X
X
516
(20.3)
X
X
X
X
X
X
X
X
N
mm
(in)
10
(0.4)
278
(11)
292
(11.5)
292
(11.5)
318
(12.5)
355
(14)
305
(12)
318
(12.5)
318
(12.5)
243
(13.5)
355
(14)
Streamline GEM Detector Dimensions
•
Dimensions are for reference only and subject to change.
• If dimensional constraints are critical, contact the factory.
