ORTEC GEM30P4 - Gamma Gage and Side-Looking Dewar Dimensions

GEM Series Coaxial HPGe Detector
Product Configuration Guide
13
DWR-S/F
CFG-PG4-1.2 (or -3 or -5) or
CFG-GG, DWR-1.2G (or -3.0G, -5.0G)
CFG-PMOD4-3 (or -7) or
CFG-GG, DWR-MOD3L (or -MOD7L)
N
ote: Cryostat/Dewar drawings are NOT to scale, see tables that follow for complete dimensions.
Dimensions are for reference only and subject to change, if dimensional constraints are critical, contact the factory.
Cryostat/Dewar or Dewar Type
CFG-PG4 and DWR-x.xG
CFG-PMOD4 and
DWR-MOD-xL
CFG-PS4, CFG-PD4, DWR-xxB and
DWR-xxD
VOLUME VOLUME VOLUME
Dim. UNIT TOL. ± 1.2L 3L 5L 3L 7L 7.5L 13L 30L
Q
mm
(in)
13
(0.5)
229
(9.0)
302
(11.9)
302
(11.9)
229
(9.0)
302
(11.9)
X
X
X
X
X
X
R
mm
(in)
10
(0.4)
X
X
X
X
X
X
X
X
X
X
174
(6.9)
174
(6.9)
155
(6.1)
S
mm
(in)
7.6
(0.3)
X
X
X
X
X
X
X
X
X
X
77
(3.0)
77
(3.0)
60
(2.3)
T
mm
(in)
5
(0.2)
X
X
X
X
X
X
X
X
X
X
10
(0.4)
10
(0.4)
13
(0.5)
Y
mm
(in)
13
(0.5)
157
(6.2)
229
(9.0)
229
(9.0)
157
(6.2)
229
(9.0)
224
(8.8)
307
(12.1)
442
(17.4)
Z
mm
(in)
5
(0.2)
229
(9.0)
267
(10.5)
419
(16.5)
292
(11.5)
320
(12.6)
452
(17.8)
429
(16.9)
610
(24.0)
Gamma Gage and Side-Looking Dewar Dimensions
• Dimensions are for reference only and subject to change.
• If dimensional constraints are critical, contact the factory.
