33 GB
QUICK GUIDE
MARKING/PINPOINT SEARCH AND PROBING
MARKING
At a distance of 5m transmitters can
be marked. To mark a located trans-
mitter, the MARKING BUTTON (8) is
pressed once. The marked transmis-
sion signal now appears as a white
symbol on a black background.
The distance to the next transmitter is
22m; the direction to the next trans-
mitter: left.
If 4 or more than 4 transmitters are
detected, the “4+” symbol appears on
the display. ORTOVOX recommends
the Sector Method for locating 4 or
more than 4 signals.
PINPOINT SEARCH AND
PROBING
Mark the exact point with the probe.
Always insert the probe at 90° to the
surface of the slope.
MARKING
BUTTON
8
