OS 22110 - Page 8

step 3.
C
D
F
B
E
D
(Y) x 3
big cam bolt
(Z) x 3
big cam lock
(Aa) x 2
1 1/4”x 3/8”dia wood
dowel with ridges
Y
Aa
(Kk) x 3
plastic cap
Z
Kk
Ii
(li) glue
1.Attach big cam bolts Y to panel F as shown.
2.Insert big cam locks Z and dowels Aa to panel E as shown.
3.Carefully align fasteners and secure part F to part E.
3.Tighten all cams.
