- 28 -
EN
Isofi x connectors
• Press the two lateral Isofi x connector buttons
in order to extend the length of the Isofi x con-
nectors.
• Guide the Isofi x connectors onto the Isofi x
anchor points on the seat of the vehicle and
ensure that they lock into position.
• Push the child car seat in until it rests securely
against the backrest of the seat of the vehicle.
Ensure that both Isofi x indicators are showing
green.
Side impact protection
• There are fold-out side impact protectors on
both sides of the child car seat.
• Please push out the protector located on the
car door side by pressing the inner button
(marked red). The protector on the inside
does not have to be folded out.
• To fold in the protector, press the inner but-
ton while pushing on the protector. Release
the inner button to keep the protector folded
in.
