osann Huddle User Manual

- 22 -
Group 1 (forward-facing)
(For children weighing 9-18 kg)
• Place the child car seat in the forward-facing position on the car seat.
• Take the car's three-point belt and extend it to the maximum length.
• Pass the three-point belt between the seat shell and the base and insert the buckle of the
three-point belt into the car belt lock until you hear it engage. (1)
• Then thread the diagonal strap through the red belt clamp. (2)
• Now pull the three-point belt as tight as possible and make sure that the
child car seat is pressed rmly against the backrest of the car seat and there is no gap. (2)
• First, open the belt system on the child car seat.
• Put the child in the child car seat.
• Make sure that the belt system and head support are correctly adjusted as described above.
• Close the belt buckle again until you hear a click.
• Pull the front adjusting strap in order to tighten the belts. Please ensure that the straps are
not twisted.
• Every time you place the child in the child car seat, make sure that the car's three-point belt
is tensioned and that the child car seat is properly secured.
EN
1
CLICK
2

osann Huddle Specifications

General

Headrest	Yes
Coloration	Monochromatic
Washing type	Machine wash
Mounting type	Seat belt
Product color	Black
Car seat group	0+/1/2/3 (0 - 36kg; 0 months - 12 years)
Country of origin	Germany
Recommended gender	Boy/Girl
Adjustable backrest	No
Belt fastening type	3/5-point
Placement available	Rear-facing
Maximum child height	135 cm
Minimum child height	40 cm
Maximum washing temperature	30 °C

Weight and Dimensions

Depth	510 mm
Width	440 mm
Height	570 mm
Weight	6400 g
Height (max)	630 mm
