- 23 -
Group 2/3 (forward-facing)
(For children weighing 15-36 kg)
Remove the belt system as described above.
Place the child car seat in the forward-facing position on the car seat.
Now thread the diagonal belt through the belt guide on the head support. (1)
Put the child in the child car seat.
Make sure that the head support is correctly adjusted as described above.
Close the buckle on the three-point belt.
Make sure that the pelvic restraint runs along the corresponding red
belt guide. (2)
Now pull the three-point belt as tight as possible so that it ts snugly against your child's
body.
Every time you fasten your child into the seat, please make sure that the car's three-point
belt is not twisted and is correctly positioned in its belt guide on the head support and in
the pelvic area.
EN
图二
C
lick
1
2

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the osann Huddle and is the answer not in the manual?

osann Huddle Specifications

General IconGeneral
HeadrestYes
ColorationMonochromatic
Washing typeMachine wash
Mounting typeSeat belt
Product colorBlack
Car seat group0+/1/2/3 (0 - 36kg; 0 months - 12 years)
Country of originGermany
Recommended genderBoy/Girl
Adjustable backrestNo
Belt fastening type3/5-point
Placement availableRear-facing
Maximum child height135 cm
Minimum child height40 cm
Maximum washing temperature30 °C
Weight and Dimensions IconWeight and Dimensions
Depth510 mm
Width440 mm
Height570 mm
Weight6400 g
Height (max)630 mm
