- 20 -
USE OF THE CHILD CAR SEAT
Setting the car seat tilt angle
• Activate the angle adjustment lever on the lower
front side of the seat bucket with one hand.
• Use your other hand to hold the reverse side of the
seat bucket and adjust the angle.
• The maximum angle is only for the rear-facing
position and the upright angle is only for the for-
ward-facing position.
The following seat positions are possible:
(Please see the label on the child car seat)
Rear-facing 9-18 kg:
1 position (1 + A)
Forward-facing 9-18 kg:
3 positions (2 + 3 + 4)
Forward-facing 15-36 kg:
1 position (5)
Turning the car seat
• Use one hand to press the red button on the front
side of the base and use your other hand to turn
the seat bucket. The twist lever can be released
whilst the seat bucket is being turned.
• There are 4 locking positions at 90, 180, 270 and
0 / 360° in the direction of the base. When the seat
bucket is in one of the positions, you can hear it
lock in with a “click” sound.
• The forward-facing position is for children in
groups 1, 2 and 3. The rear-facing position is for
infants in group 1. (9-18 kg)
Only forward-facing Only rear-facing
90°270°
0/360°
180°
Adjustment of the belt
• To loosen the belt, press the button for belt adjust-
ment in seat area with one hand.
• Use your other hand to hold the buckle in place
with the attach belts and then release it.
• To secure the belt, pull on the front adjustment
belt.
Adjustment of the head support
height
• Release the belt and pull the red lever to set the
head support to the right height on the reverse
side.
• Release the lever and ensure that the head sup-
port is locked.
Opening/closing the belt
• To unlock the belt, press the red button of the
buckle and separate the two tongues of the buck-
le.
• To lock the belt, rst connect the 2 tongues of
the buckle and then insert them together into the
buckle.
EN
