- 22 -
Installation with Isox
• Insert the black insertion aids through the slit in the
cushion between the back rest and seating area
and into the Isox holders.
• Ensure that the at side is pointing downwards.
This is not necessary if the vehicle already has
rmly installed insertion aids.
• Press the two lateral Isox connector buttons in
order to extend the Isox connectors to their full
length.
• Insert the Isox connectors into the insertion aids
and press until you hear them lock.
• The display on both sides only turns green when
the connections have been established. Press the
child car seat against the back rest until it is stand-
ing securely.
Installation with Top-Tether
• Remove the Top-Tether from the bag.
• In order to loosen the Top-Tether, press the grey
adjustment button with one hand and pull the side
of the belt anchor to the required length with your
other hand.
• In order to ax the Top-Tether, hang the anchor to
the xation point on the car seat and pull it as tight
as possible. The display does not turn green until
the belt is locked.
A B
C D
EN
Removal of the belt system
• Loosen the belt
• Pull the belt system and the cushion out of their metal brackets on the reverse side
of the child car seat and guide these through the child car seat to the front side
(Fig. A)
• Remove the shoulder pads and the belt buckles from the belt.
• Fold the belt together so that it can be stored in the hollow on the back rest behind the
cover. (Fig. B)
• In order to remove the belt buckle, rst move the seat into its maximum lying position. Then
rotate the seat into the 90° position.
• Remove the cover and move it to the side. (Fig. C)
• Now bring the metal clip of the belt buckle through the opening and ax the cover again
after this (Fig. D)
• Ensure that you retain all the parts that are removed in a safe place.
