Page 11
Installation and Operation Manual - 1700
ENGLISH
2.3.2 Stove Dimensions with Structural Legs
12 1/2"
316mm
24 7/8"
632mm
Ø
6"
150
mm
6 5/8"
167mm
Figure 4: Top View
25"
635mm
24 1/2"
622mm
15 3/4"
399mm
9 3/8"
239mm
10 7/8"
276mm
17 1/2"
444mm
19 1/4"
490mm
23 1/4"
590mm
22 3/4"
578mm
11 3/8"
289mm
17 5/8"
449mm
10 1/8"
256mm
28 1/2"
725mm
27 1/2"
698mm
Figure 5: Front View Figure 6: Side View

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Osburn 1700 and is the answer not in the manual?

Osburn 1700 Specifications

General IconGeneral
Heating Capacity500 - 1, 800 sq. ft.
Maximum Output65, 000 BTU/h
Chimney Diameter6 inches
EPA CertifiedYes
Firebox MaterialSteel
Maximum Log Length18 inches
Efficiency77% (LHV)
