20
2.10 Baffle & brick installation
CAUTION: Operation of your Osburn insert without the baffle may cause unsafe and hazardous
temperature conditions and will void the warranty. NOTE: Before installing the
firebrick, check to ensure that none are broken or damaged in any way. If so, have
the damaged ones replaced. Check the firebrick for damage at least annually and
replace any broken or damaged ones with new ones. Inspection and cleaning of
the chimney is facilitated by the removable baffle.
The stove is shipped with all firebricks in place except for the top 3 at the rear of the firebox and
the top sides (2 per side, 1 full and 1 partial). The balance of the loose bricks are for the baffle.
Install three top rear firebricks. The two full 9" (229 mm) bricks are on either side and are to be
installed first. Then place the 7" (178 mm) brick in the center . Install the full 9" (229 mm) bricks
on each side toward the rear of the firebox. After the 9" (229 mm) bricks are in place, install the
partial 5 1/2" (140 mm) bricks on each side. The firebox bricking procedure will now be
complete.
To install the baffle, follow the instructions on the next page. To remove, reverse the procedure:
