Osburn 2400 Insert User Manual

22
Figure 2.10b
ITEM PIECE # DESCRIPTION QTY
1 29020 4 1/2" X 9" X 1 1/4'' REFRACTORY BRICK 12
2 PL36058 4" X 9" X 1 1/4'' (COUPE 1'' X 1'') REFRACTORY BRICK 2
3 29011 4" X 9" X 1 1/4'' REFRACTORY BRICK 8
4 PL36014 4" X 6 1/2" X 1 1/4'' REFRACTORY BRICK 2
5 PL36048 4" X 4" X 1 1/4'' REFRACTORY BRICK 1
6 29001 4" X 8" X 1 1/4'' REFRACTORY BRICK 3
7 PL39027 REAR BRICK RETAINER 2
8 PL39015 FRONT SECONDARY AIR TUBE 1
9 PL39018 REAR SECONDARY AIR TUBE 2
10 30068 1/8'' X 1 1/2'' STAINLESS STEEL COTTER PIN 3
11 PL39013 2400 SERIE BAFFLE SIDE HOLDER 2
12 21297 23 7/8'' X 8 1/4'' X 1 1/4'' C-CAST BAFFLE
2
13 PL39047 16 3/8'' X 25'' X 1/2'' BAFFLE INSULATION BLANKET 1
14 PL34026 INSULATION BLANKET WEIGHT 1
