Page 10
Installation and Operation Manual - Inspire 2000
2.1.4 Combustion Chamber Dimensions
8 1/4"
211 mm
20"
508 mm
21"
535 mm
Figure 12: Door opening Figure 13: Front view - Combustion chamber
13 3/4"
348mm
16 7/8"
429mm
11 7/8"
303mm
3/8"
10mm
3/16"
5mm
Figure 14: Side view - Combustion chamber
