ELECTRICAL WIRINR & SYSTEM
MIRES
- åre all numbered (see enclosed list).
All E'arth-connections have a zero (ø) in
front of the number and these wlres åre all
BLflCK.'
Examole: 35 (red) + to fan suvitch
035 (black) Earth to fan motor
Earth terminal: is positioned in centre of
electrical panel under scuttle and
in front of instrument panel.
Extra e ui ment: (f. inst. air-condition)
has no numbers on the wires.
General:
The whole system is based on the fusebox and
junction box from VOLVO 340 (1981 . to 83), and
all numbers refer to these units.
Arrows an wires always point towards Earth "thrQugh
the consuming unit".
OScar WIRING-SYSTEM
All wires åre numbered after the following system:
3 (green) + on coil
4 (brown) horn push - |
7 (red) generator D+ l
11 (yellow) starter relais ;
12 (blåck) oil temp. plck-up |
16 (white) parking light LH side ;
17 (white) rev. counter
18 (grey) low headlight LH side
19 (red) high - - -
20 (blue) oil pressure pick-up
21 (green) trafficators LH side
24 (yellow) + to horn
28 (red) water temp. pick-up
.
51 (green) wiper switch
35 (grey) IOIN headlight RH side
36 (grey) parking light
37 (blue) trafficators -
43 (red) high headlåmps RH side
47 (brown) horn push *
48 (red) + to ignition key
50 (black) + from ignition key
52 (red) amp. meter-lamp
53 (yellow) froni ignition switch to starter
54 (browh) high headlamps signal *
55 (grey) light-switch low/high
57 (blue) - - +
58 (white) - - parking lights
59 (green) oil pressure warning light
60 (blue) ignition switch to relais
61 (white) rev. counter *
62 (toiaek) wiper switch *
63 (white) parking lights-lamp (in instr. panel)
64 (yellow) trafficator switch
64 (white) hazard light switch
64 (red) relais for overdrive *
65 (green) instrument panel light *
67 (brown) handbrake
67 (blue) brake failure warning lamp *
69 (broiAin) lighter *
70 (green)
71 (red)
72 (red)
73 (black)
74 (yellow)
78 (white)
79 (grey)
80 (blue)
81 (green)
84 (black)
85 (red)
86 (blue)
87 (blue)
88 (red)
98 (brown)
98 (green)
100 (red)
101 (black)
102 (blue)
104 (yellow)
105 (yellow)
107 (red)
108 (yellow)
109 (green)
111 (whÆte)
115 (brown)
200 (black)
201 (red)
202 (red)
207 (red)
hazard-light-switch
water-Æejnp-gauge *
+'for instrument panel lamps
gearbox-switch for reverse light
brake-lights
rear lamp LH side *
RH - *
+ to relais "bridge"
trafficator LH side *
earth to relais in fusebox
+ to fan svirÆtch (heater) *
trafficator RH side *
wiper motor and switch *
+ to boot lock & luggage room light *
impuls for bootlid lock
from 15 (R) an ignition switch to
bootlid switch
earth for oveiGlfive switch on gearbox
overdrive switch in gearlever
lamp in panel
relais in gearbox
fan motor
fuel-gauge-units
switch for instrument panel lamp
uuiper motor
generator B+
starter B+
to "90" on fusebox
+ to all instruments in panel
*) wire in question goes to fuse box.
