OSHIMA K5 - Page 67

K5-190 零件表 Parts List 3D-8
NO.
零件号
名称
Compellation
NO.
零件号
名称
Compellation
1
K5A012
底盤 A
Lower Cover A
10
K5A066
對邊 LS( 7121)板
Stand of Limit SW 7121
2
K5A013
底盤中
Mid. Lower Cover
11
KS3A062
線槽蓋
Cover
3
K5A014
底盤 B-190
Lower Cover B
12
KS3A061
線槽
Cord Chase
4
K5B009
尾幹管-190
Rear Frame Join-pipe
13
K5A063
升降軸上蓋補助片 1
Assist Plate 1
5
K5B007
中幹管-190
Mid Frame Join-pipe
14
K5A064
升降軸上蓋補助片 2
Assist Plate 2
6
K5B008
前幹管-190
Front Frame Join-pipe
15
A7064
方型幹管座 A
Stand A of Square Joint Pipe
7
K5A011
對邊馬達座
Stand of Edge Motor
16
A7065
3 孔墊片
Washer
8
CS2B080
對邊馬達齒輪 M1.5*25T
Gear
17
B9001-190
方型幹管-190
Square Joint Pipe
9
04.04.18.1002
對邊馬達
Edge Motor
18
04.04.13.0111
限位開關 TZ-7121
Limit Switch
