OSHIMA K5 - Page 70

K5-190 零件表 Parts List 3D-10
NO.
零件号
名称
Compellation
NO.
零件号
名称
Compellation
1
K5A019
解布槽-190
Unwinding Chase
31
K5B051
解布助落滾輪軸 A
Shaft
2
K5A079
解布槽固定耳
Stand of Unwinding Chase
32
K5B031
助落滾輪 PU 帶頭
Pulley
3
04.04.01.2002
三色燈
Indicator
33
K5B028
解布助落滾輪
Roller
4
K5B042
頂架上撐板軸
Shaft
34
K5A040
墊片
Washer
5
K5A035-L
頂架上撐板 A
Support Plate A
35
K5B079
墊圈
Washer
6
K5A036
上撐板撥開器 A
Push Aside Unit A
36
K5B078
前柱滾輪軸
Shaft
7
K5B043
頂架鋁管端軸
Shaft
37
K5B025
前柱滾輪
Roller
8
K5B044
頂架鋁管
Al-Pipe
38
K5A073
斜展輪扁管臂
Arm of Rectangle Pipe
9
KS3B191
斜展輪板鋁圈套 A
Al-Sleeve
39
K5B019
布台壁白鐵連桿
Joint Pipe
10
K5B048
頂架白鐵連桿
Joint Stainless Pipe
40
K5A026
解布光電座
Stand of Photo Sensor
11
KS3B192
斜展輪板鋁圈套 B
Al-Sleeve
41
04.04.14.1101
解布 光電開關 CX-29
(CX491)
Photo Sensor
12
K5B045
頂架鋁連桿
Joint Al-Pipe
42
KS3B201
上展布輪軸
Upper Expanding Roller Shaft
13
KS3A079-L
上斜展輪板 A
Upper Extend Plate A
43
KS3B200
上展布輪
Upper Expanding Roller
14
KS3B203
斜展輪軸心
Shaft
44
K5A023
下斜展輪板 B
Lower Extend Plate B
15
KS3B202
斜展輪
Extend Roller
45
K5A075
下斜展定位板
Position Adjuster
16
KS3A078
斜展輪座
Stand of Extend Roller
46
K5B077
下斜展定位板軸
Shaft
17
04.07.05.1003
梅花螺絲 M8*25
Screw
47
K5B021
斜展輪扁管
Rectangle Pipe
18
KS3A079-R
上斜展輪板 B
Upper Extend Plate B
48
K5A076
下斜展輪板座
Stand of Lower Extender
19
K5A021
頂架壁 A
Upper Frame A
49
K5A020
下斜展輪板 A
Lower Extend Plate A
20
K5A089
三色燈座
Stand of Indicator
50
K5A077
斜展輪板座 B
Side Extend Plate B
21
K5A037
頂架臂 A
Upper Arm A
51
K5B072
頂架柱 B
Al-Pole B
22
K5B046
解布滾輪軸 A
Shaft
52
K5B050
解布助落滾輪軸 B
Shaft
23
K5B047
解布滾輪軸圈套
Sleeve
53
K5A024
布台板
Cover of Platform
24
KS3B170
解布滾輪 A 側培林頭
Stand of Bearing
54
K5A074
斜展輪扁管臂 B
Arm of Side Expanding Pipe B
25
06.10.01.3001
解布助落滾輪 PU 帶
PU Belt
55
K5B073
穩布桿臂
Arm of Stable Pipe
26
06.10.03.3002
解布滾輪皮
Sponge
56
K5A071
墊圈
Washer
27
K5B022
解布滾輪
Unwinding Roller
57
K5B074
穩布桿
Stable Pipe
28
K5B071
頂架柱 A
Al-Pole A
58
K5B075
穩布桿臂軸柱
Shaft
29
K5B080
上外殼柱 U
Pole
59
K5A072
穩布桿臂軸柱壁
Beetle Plate
30
K5B081
上外殼柱 D
Pole
60
K5B037
PU 膠
PU Sleeve
