21
EN
S
S
ON
1
2
3
4
ON
1
2
3
4
ON
1
2
3
4
L
N
L
N
L
N
L(2)
N(3)
LT(1)
L(2)
N(3)
LT(1)
L(2)
N(3)
... 150 Z1T
... 150 Z1PCT
Operation mode 1
Operation mode 2 Operation mode 3
Fan does not run
S switch to ON
or pull cord switch
Activation of turn-off
delay timer (0-2 minutes)
S switch is OFF
during countdown of turn-on
delay timer
Yes
No
Fan runs at speed 1
S switch to ON
or pull cord switch
Fan does not run
S switch to ON
or pull cord switch
Activation of turn-off
delay timer (0-2 minutes)
S switch is OFF
during countdown of turn-on
delay timer
Fan runs at speed 2
S switch to ON
or pull cord switch
Да
Нет
Fan runs at speed 1
S switch to ON
or pull cord switch
Fan runs at speed 2
S switch is OFF
during countdown of turn-on
delay timer
No
Yes
Activation of turn-off
delay timer (0-2 minutes)
S switch to ON
or pull cord switch
15.
