How to Install the Panel Heater
Please use the mounting brackets supplied. The heater should be positioned
observing the minimum clearances stated around the heater - see Fig. 1
Step 1. First remove the wall bracket from the rear housing.
Unscrew the screws located on the top of the 2 vertical bars
of the wall bracket.
Step 2. Then pull out the top bar by pressing firmly both upper
parts slotted into the rear housing. Slide down the wall bracket in
order to remove it from the rear housing.
Step 3. Fix the wall bracket securely to the wall through the 4
screw holes provided.
Step 4. Raise the heater to upright position. Present the heater and
engage 2 slots ofthe bottom parts of the wall brackets in the wall
heater’s rear enclosure then pull up the heater. Then engage 2
slots of the upper parts of the wall bracket and tighten the 2
screws in order to lock the device.
(
