OTC 5015A - Parts Information; Parts List; Optional Accessories

Parts List & Operating Instructions
Item
No.
Part
No.
No.
Req'd
Description
1 540573 4 Nut (M12 x 1.75)
2 545602 4 Lockwasher (12 mm)
3 542035 2 Leg Weldment
4 542187 2 Strap
5 540891 7 Cap Screw (.500-13 x 38 mm)
6 540570 1 Locknut
7 541036 8 Plain Washer
8 542617 2 Washer
9 545515 6 Bushing
10 540785 2 Washer
11 542610 1 Cap Screw (.500-13)
12 542184 1 Tube
13 542036 1 Upper Lift Arm Weldment
14 541038 2 Cap Screw (.500-13 x 25.4 mm)
15 542616 1 Plate
16 545765 1 Splined Shaft (2" dia.)
17 542608 1 Cap Screw (.625-11)
18 542613 1 Lockwasher (.625)
19 542034 1 Lower Lift Arm Weldment
20 542027 1 Jack Yoke Weldment
21 600003* 1 Hydraulic Bottle Jack
22 542607 2 Cap Screw (M6-1)
23 542612 2 Nut (M6-1)
24 542614 2 Lockwasher
25 542026 1 Jack Mount Weldment
26 542609 3 Cap Screw (.437-14)
27 542615 4 Lockwasher (.437)
28 542611 5 Nut (.438-14)
29 545518 1 Handle Holder Stud
30 545516 2 Cap Screw (.500-13)
31 12330 2 Washer
32 542185 1 Tube
33 542186 1 Tube
34 542037 1 Cross Frame Weldment
35 540568 4 Swivel Caster
36 10208 8 Nut (.500-13)
37 541030 8 Lockwasher
Parts Included But Not Shown
545621 1 Trade Name/Warning Decal
Optional Accessories
48625 1 Splined Shaft (1-3/4" dia.)
218174 1 Flywheel Adapter (see Form #105665)
Form No. 545622, Sheet 1 of 3, Back
* Depending on your model, you may or may not need the extra parts included in this kit.
Refer to any operating instructions included with the product for detailed information about operation,
testing, disassembly, reassembly, and preventive maintenance.
Items found in this parts list have been carefully tested and selected by OTC. Therefore: Use only OTC
replacement parts!
Additional questions can be directed to the OTC Technical Services Department.
