OTC 5078 - Parts List & Operating Instructions

Parts List & Operating Instructions Form No. 106329, Sheet 1 of 3, Back
Description
Item
No.
Part
No.
No.
Req'd
1 12365 4 External Retaining Ring
2 11903 1 Retaining Ring
3 54626 1 Main Base Assembly
4 19802 3 Abrasive Roll
5 10559 16 Hex Hd. Cap Screw
6 10257 16 Washer (for 5/16" bolt)
7 10201 16 Hex Nut (5/16-18)
8 16002 4 Caster
9 314726 1 Hydraulic Hose (30 in.)
10 11628 1 Straight Fitting
11 66226 1 Air Hydraulic Foot Pump
12 46963 1 Decal
13 314743 1 Warning Decal
14 223514 1 Decal
16 15997 1 Cotterless Hitch Pin
17 222237 2 Pivot Shaft
18 222238 1 Pivot Shaft
19 314152 2 Threaded Rod
20 222239 1 Hex Hd. Cap Screw
21 10093 1 Hex Hd. Cap Screw
22 15013 3 Hex Locknut (1/2-13)
23 314748 1 Strap
24 10089 1 Hex Hd. Cap Screw
25 314733 1 Front Support Bracket
26 314734 1 Mounting Plate
27 314730 1 Back Support Bracket
28 440400 1 Pivot Linkage Assembly
29 222235 2 Slotted Hex Nut
30 214021 4 Thrust Bearing Washer
31 10895 4 Roll Pin
32 222236 1 Pivot Shaft
33 314735 2 Handle
34 314154 1 Pivot
35 12004 3 Washer (for 1/2" bolt)
36 10079 3 Hex Hd. Cap Screw
