User’s Guide of DO3000 Door Operator
Lead the green future All rights reserved © OTIS 3/48
1. Product Introduction
DO3000 permanent-magnetism frequency-conversion door operator is a door drive system which is driven
by the permanent magnet synchronous motor and controlled by stepless speed adjustment and frequency
conversion system. It can achieve the best open/close speed curve, with the features such as efficiency,
reliability, simple operation and less mechanical vibration. DO3000 permanent-magnetism
frequency-conversion door operator applies to the door system with the net door width of (700 ~ 1800)
mm.
Main characteristics are as follows:
1 Synchronous motor angle learning (static)
2 Door width learning
3 Automatic open/close demonstration
4 Fault alarm and automatic protection
5 Baffle detection selection
6 Synchronous/asynchronous door coupler selection
1.1. Technical Parameters
Input voltage: AC220V±20%;
a) Controller:
Rated frequency: 50/60Hz;
Output voltage: 0～220V;
Output frequency: 0～50Hz
b) Motor:
Rated voltage: AC80V;
Rated speed: 180r/min;
Rated power: 94W
1.2. Working conditions
a) Altitude 1000m below, 100% rated current output;
1000~2000m, 95% rated current output;
2000~3000m, 85% rated current output;
b) The maximum relative humidity of the wettest month at site is 95%, and the average monthly
minimum temperature is not higher than 25 ℃;
c) The fluctuation of supply voltage relative to the rated voltage should be within ±15%
d) Ambient air should not contain corrosive and flammable gases and conductive dust;
