User’s Guide of DO3000 Door Operator
Lead the green future All rights reserved © OTIS 40/48
Functio
n No.
Name
SVT Display
Setting Range
Defau
lt
Rang
e
Attribute
9
Low limit of
run count
Run Count(1)
※
M312 (Monitoring parameters B)
0
DC bus
voltage
DC link V
0~9999v
※
1
ST code
status
ST1 ST2 ST3
Based on the
actual conditions
※
2
Encoder
position
Encoder
position
0~65536
※
3
Current
location
Door position
00000
※
4
INPUT1
INPUT1
※
5
INPUT2
INPUT2
※
M313(Monitoring parameters C)
0
Open input
Key open door
False
※
1
Close input
Key close door
False
※
2
Stop
Stop press
ENTER
False
※
M3311(Field adjustment parameters)
0
REV
normally on/
off selection
REV NO/NC
0: normally on
1: normally off
1/0
For
HAA24360G1/2/5/6/7/10/
11, it is 1, and for
HAA24360G3/4/8/9, it is
0
1
Rotation
direction
negation
Rotate dir 1/0
0,1
1
2
Run
command
source
RUN comd
source
0~3, 5~6
1 Single run
2 Continuous
run
3 DO/DC
5 Basic mode
of ST code
6 Extension
mode of ST
code
6/3
For
HAA24360G1/2/5/6/7/10/
11, it is 6, and for
HAA24360G3/8, it is 3,
and for HAA24360G4/9,
it is 5
3
Door range
DR half range
mm
0~65535
■
4
Open
low-speed
distance
Open low dis
mm
0~100
5
5
Open start
unlock
speed
Open unlock
mm/s
5~100mm/s
60
