User’s Guide of DO3000 Door Operator
Lead the green future All rights reserved © OTIS 41/48
Functio
n No.
Name
SVT Display
Setting Range
Defau
lt
Rang
e
Attribute
6
Open start
unlock
distance
Open unlock S
％
0~30.0%
5.0%
7
Open
acceleration
Open accel
mm/s2
10~2048mm/s/s
800
8
Open jerk
acceleration
Open Jerk0
mm/s3
10~2048mm/s/s/
s
800
9
Open
deceleration
Open Decel
mm/s2
10~2048mm/s/s
800
10
open jerk
deceleration
Open Jerk1
mm/s3
10~2048mm/s/s/
s
800
11
Close arrive
speed
Clos arrive
mm/s
5~100mm/s
25
12
Close
low-speed
distance
Close low dis
mm
5~100
60
13
Close
acceleration
Clos accel
mm/s2
10~2048mm/s/s
700
14
Close jerk
acceleration
Clos Jerk0
mm/s3
10~2048mm/s/s/
s
700
15
Close
deceleration
Clos Decel
mm/s2
10~2048mm/s/s
600
16
Close jerk
deceleration
Clos Jerk1
mm/s3
10~2048mm/s/s/
s
600
17
Close start
unlock
speed
Clos unlock
mm/s
5~150mm/s
35
18
Close start
unlock
distance
Clos unlock s%
0~30.0%
0.5
19
Password
Password
0~9999
8888/
4321
M3312 (Regulator parameters)
0
Proportional
gain1(high
speed)
SpdP1 gain
0~10000
1000
1
Integral
gain 1(high
speed)
SpdI1 gain
0~10000
800
2
Proportional
gain2(low
speed)
Spdp2 gain
0~10000
1000
3
Integral
gain 2(low
speed)
SpdI2 gain
0~10000
800
4
PI switching
threshold
value
SGP tran21h thr
%
0~100
5
5
PI switching
band width
SGP tran21
band%
0~100
5
