Functio
n No.
Name
SVT Display
Setting Range
Defau
lt
Rang
e
Attribute
6
Speed
feedback
filtration
Sfbk filter
0～66 (high/low)
33
7
Proportional
filtration by
reference to
torque
Prop filter
0~3
0
8
Motor
overspeed
overspeed (pu)
1.00~2.00
1.0: Rated RPM
1.25
9
Regulation
method
Regulation
methord
0:VF
1: closed ring of
asynchronous
motor
2: Synchronous
motor
2
10
Feedback
mode
Feedback mode
0: DO/DC
open/close
signal
1: ST code
open/close
signal
1/0
For HAA24360G3/8
component, it is 0
11
Current
loop KP
Curp gain
0~9999
512
12
Current
loop KI
Curi gain
0~9999
150
13
Motor
torque limit
(open)
OP DRV Limit
PU
0.00~2.50
2.00
14
Brake
torque
limit(open)
OP REG Limit
PU
0.00~2.50
2.00
15
Motor
torque
limit(close)
CL DRV Limit
PU
0.00~2.50
2.00
16
Brake
torque
limit(close)
CL REG Limit
PU
0.00~2.50
2.00
17
Overload
protection
coefficient
of motor
Mtr ovl i fac PU
0.1~2.0
1.2
18
PVT
protection
sensitivity
factor
PVT threshld
min
0~10
0: disable
The greater the
number, the
lower the
sensitivity
0
M3313(Motor parameters)
0
Motor
power
Rated Power
0.1~999.9KW
94.3
1
Number of
poles
Number of poles
0002~0016
0016
