User’s Guide of DO3000 Door Operator
Lead the green future All rights reserved © OTIS 43/48
Functio
n No.
Name
SVT Display
Setting Range
Defau
lt
Rang
e
Attribute
2
Rated RPM
Rated RPM
1~9999
0180
3
Rated
frequency
Rated frq
1.00Hz~99.99H
z
24.00
4
Rated
voltage
Rated voltage
0~999V
80
5
Rated
current
Rated I (A)
1.0~999.9
001.0
6
Roller
diameter
Shv diam mm
10~10000mm
00045
7
Gear ratio
Gear ratio
1.0~100.0
001.0
8
Rope ratio
Rope ratio
1~6
1
9
Rotor
position
offset
Rotor pos offset
0~65535
■
10
Stator
resistance
resisit s
0.000~9.999 Ω
2.790
11
Stator
inductance
Induct s(mH)
0.0~999.9mH
252.4
12
Rotor
resistance
Resist rotor
0.000~9.999Ω
1.820
13
Rotor
inductance
Induct r(mH)
0.0~999.9mH
252.4
14
Mutual
inductance
mutual induct
0.0~999.9mH
240.6
15
No-load
current
No load current
0.0~999.9A
2.7
M3314(Drive scaling parameters)
0
Drive No.
Drive Size
0~100
000
1
Rated
voltage
Drv Rtd Volt (V)
0~1000
0220
2
Rated
current
Drive Rtd i RMS
(A)
0.0~999.9
002.5
3
Current
adjustment
factor
Drv i fscale (A)
0.000~2.000
1.50
4
Voltage
adjustment
factor
Bus fscale (V)
0.000~2.000
1.050
5
Current limit
(overcurrent
)
Drv i limit (A)
0.0~999.9
005.0
6
Bus
overvoltage
point
Bus ovt (PU)
0.00~2.00
1.4
7
Bus
undervoltag
e point
DC link UV (PU)
0.00~1.00
0.60
8
Input
voltage
Line fscale (V)
0.00~2.00
1.00
