User’s Guide of DO3000 Door Operator
Lead the green future All rights reserved © OTIS 44/48
Functio
n No.
Name
SVT Display
Setting Range
Defau
lt
Rang
e
Attribute
coefficient
9
Brake
voltage
M1 pick V (PU)
0.00~1.00
1.00:1000V
0.35
10
Dead time
Drv dead time
(us)
2~20
03
11
PWM
compensati
on
Drv PWM comp
PU
0.00~2.00
1.00
12
Over
modulation
factor
Drv k mod (PU)
0~100
100
13
Carrier
frequency
Switch frq (PU)
0～12 KHz
10
14
Running
time (hours)
Run time hour
0~65535H
Power-down
save
※
*
15
Running
time
(minutes)
Run time
second
0~59MIN
Power-down
save
※
*
M3315(Enhanced parameters)
0
Run hold
time
Run hold time
0~99.9s
0: continuously
run
Others: stop
when time is up
00.0
1
Power-on
speed
Power on V
mm/s
10~100mm/s
0050
2
Door range
measureme
nt speed
Learn V mm/s
10~100mm/s
0050
3
Close arrive
response
time
Close arrive
200~3000ms
2000
4
Open arrive
response
time
Open arrive
500~3000ms
Torque hold is
activated after
arrive
800
5
Arrive signal
selection
Arr sw select
0: Yes for open
arrive and close
arrive
1: None for open
arrive and yes
for close arrive
2: None for open
arrive and close
arrive
1
6
Open hold
torque
Open hold
torq%
0~200.0%
090.0
%
7
Close hold
torque
Close hold
torq%
0~200.0%
100.0
%
8
Baffle
Baffle timer
0~999ms
200
