User’s Guide of DO3000 Door Operator
Lead the green future All rights reserved © OTIS 45/48
Functio
n No.
Name
SVT Display
Setting Range
Defau
lt
Rang
e
Attribute
detection
time
ms
0: non-function
9
High speed
baffle
torque
Baffle torq Hi %
0~200.0%
Baffle torque at
acceleration
120.0
%
10
Close
constant
baffle
torque
Baffle torq Mid
%
0~200.0%
Baffle torque
(ACC=0)
70.0
%
11
Low-speed
baffle
torque
Baffle torq Lo %
0~200.0%
Baffle torque at
deceleration
105.0
%
12
RY1
function
selection
Ry1 function
0: open arrive
signal (open/
close or pulse)
1:Close arrive
signal (open/
close or pulse)
2:fault output
3: Baffle
detection output
4: Open output
5: Close output
6:Limit open
arrive signal
7: Limit close
arrive signal
8: DOS
9: DOL
0
13
RY2
function
selection
Ry2 function
8/1
For
HAA24360G1/2/5/6/7/10
/11, it is 8, and for
HAA24360G3/4/8/9, it is
1
14
Stop closing
torque
function
CL low torq
0~2000 %
0: non-function
100%: 5Nm
motor torque
Enabled,
recommended
setting is≥30%,
can be adjusted
0
15
Open arrive
limit
Open limit mm
0~1000mm
10
16
Open speed
Open speed
mm/s
0~508mm/s
0508
17
Open arrive
speed
Open arrive
mm/s
5~100mm/s
020
18
Door
coupler type
Door Coupler
0/1/2
0: Asynchronous
door coupler
1: Synchronous
door coupler
2: Integrated car
door
synchronous
door coupler
2
19
Close arrive
Close limit mm
0~1000mm
10
