User Manual
• Alternatively you can unpair your device by holding down the Bluetooth button on the remote control for
5 seconds
● Volume Operation
• Press the Vol+ Key to increase the volume.
• Press the Vol- Key to decrease the volume.
● Mute Function
• In normal usage, press Mute on the remote control to activate the mute function (no audio output when
mute function is active). When mute function is active, all the key functions will be locked (except Mute,
Vol+ and Vol- keys). The “MUTE” icon will flash on the screen.
• Press Mute again to cancel the mute function. The screen will show the current volume for 1 second
and resume back to the normal operation mode display.
Pressing Vol+ or Vol- on either the speaker or the remote will also cancel the Mute function.
● iPod Operation
• Press MODE to select iPod mode.
‘IPOD’ will be displayed on the screen to indicate the mode has been selected.
● Installing the Dock
• To use the docking feature, you will firstly need to remove the flat docking cover, do this by gentle
pushing down on one side of the cover, this will cause the other side to raise up. Now gentle insert a
fingernail or other thin object under the cover and lift it off.
• Select the correct connector for your model phone (there is an option for iPhone 30 pin, iPhone
Lightening and Micro USB).
• On the underside of the dock there are two sliding buttons; pinch these together to open the connector
clips and at the same time insert the phone connector into the slot in the topside of the dock, then
release the buttons. The connector will now be securely inserted in the dock. Note: The connector can
only be placed in one way, please look to align the notch correctly.
*Now you can place the dock into the slot on the top of the main speaker.
8
a.The screen will show the volume level for one second (levels go from 0 to 40, with 40
being the maximum).
a.When volume is reduced to the minimum volume level (Volume ‘0’), the speaker will
change to Mute mode
