► In case of changes in or loss of functionality, do not continue using the
product (see "Signs of changes in or loss of functionality during use" in
this section).
► Take any necessary measures (e.g. repair, replacement, inspection by
the manufacturer's customer service, etc.).
Signs of changes in or loss of functionality during use
Reduced spring effect (e.g.decreased forefoot resistance or changed
rollover characteristics) is an indication of loss of functionality.
4 Scope of delivery
Quantity Designation Article number
1 Instructions for use –
1 Prosthetic foot –
Spare parts/accessories (not included in the scope of delivery)
Designation Reference number
Connection cap 2C10*, 2C11*
5 Preparation for use
CAUTION
Incorrect alignment or assembly
Risk of injury due to damaged prosthetic components
► Observe the alignment and assembly instructions.
NOTICE
Grinding the prosthetic foot or footshell
Premature wear resulting from damage to the product
► Do not grind the prosthetic foot or footshell.
5.1 Alignment
5.1.1 Bench Alignment
TT bench alignment
Bench alignment process
Required materials: 662M4 goniometer, 743S12 heel height measuring apparatus,
743A80 50:50gauge, alignment apparatus (e.g.743L200 L.A.S.A.R. Assembly or
743A200 PROS.A. Assembly)
Perform the assembly and alignment of the prosthetic components in the alignment
apparatus according to the following specifications:
12
