S3 User Guide 3 PN 875-0196-000 Rev C1
Chapter 1: Introducing the S3
Figure 1-1 shows some of the parts that comprise an S3 kit, Figure 1-2 illustrates the
S3 wiring connections, and Table 1-1 on page 4 provides part numbers and
descriptions.
Figure 1-1: Outback S3 kit components
Figure 1-2: S3 connection diagram
H
C
A
B
D
E
F
G
I
J
E
C
D
A
J
To eDriveTC/eDriveVSi/
eDriveX console
To batte ry
