Chapter 1: Introducing the S3
For the Ram ball mount assembly, Figure 1-3 provides a parts/connection diagram and
Table 1-2 provides component descriptions.
Figure 1-3: Ram ball mount assembly
Table 1-2: Ram ball mount assembly part descriptions
Item Part No. Description Qty
1 RAM202U Round base 1
2 RAM-201U Double socket arm mount 1
3 RAM235U Bar mount base 1
4 RAM235U U-bolts for 3/4" to 1 1/4" diameter bars 2
