Outsunny Fire pit - Step 1: Attach Handle to Mesh Cover; Step 2: Attach Legs to Fire Bowl and Base Ring; Step 4: Place Mesh Cover and Final Check

Step 1: Attach Handle (A) to Mesh Cover (B) using Nut (BB). Fully tighten the nut.
Step 2: Place the Base Ring (E) on the bottom of Fire bowl (C), Attach Legs (D) to Fire Bowl (C) using M6 x
10mm Bolts (AA), do not tighten the bolts. Then attach Legs (D) to Base Ring (E) using M6 x 10mm
Bolts(AA) . Tighten all the hardware.
Step 4: Place the Mesh Cover (B) on the fire bowl (C) in order. Keep Poker (F) near the fire pit for use
anytime. Now the fire pit is ready for use.
AA
C
E
D
AA
B
C
F
BBx1
AAx12
