Overade OxiBrake - Pairing OxiBrake with Other Lights; Successful Pairing Indicators; Alternative Pairing Outcomes

[A] - PAIRING OXIBRAKE WITH OXILUM OR OXITURN LIGHT
*Repeat the pairing process if not successful.
*If OxiBrake button lights up alternately in red and green after pairing instead of continuously, this means that OxiBrake
cannot be paired with additional products. Delete all pairings in order to pair a new one (see [B]).
On the light,
switch on the light by
pressing and releasing
the button
Press and hold the button
(at least 6s) until the button
flashes orange
On OxiBrake,
press and hold the button
(at least 6s) until it
flashes red&green
1
2
=> If the pairing is successful:
- the light button lights up
continuously in orange for a
few seconds and then
turns off
- OxiBrake button lights up
continuously in red&green
for a few seconds and then
turns off
=> Other cases*
3
3
2
1
EN
Dec. 2022 OxiBrake Guide 8
